The prepackaged drum filtration assembly includes a 5” steel inlet filter canister and contains all of the parts required making it easy to install. The air filter canister has a radial lip element that provides acoustic tuning to decrease blower noise. The Air Filter kit is packaged with the main items required to mount the filter and protect your positive displacement blower.
FEATURES:
- Can be used for for vacuum or pressure duty
- 4" Camlock for vacuum service
- Removable foam pre-cleaner element for cleaning and reuse, in addition the foam pre-cleaner increases service life
- Filter lid and screen designed to give minimal restriction and keep out water O-Ring type gasket seals top and bottom assemblies for maximum protection
- Powder coated finish
DIAGRAM:
302HTF6003
GD Kit D807/907 Pres/Vac SS Inlet
